Yale YDM7220 BioSecure

Yale YDM7220 BioSecure

A multi-credential mortise lock for a substantial door. YDM7220 BioSecure brings fingerprint, code and tag access to a lever-style assembly, with a mechanical override and provision for Yale connectivity. The specified 45–90 mm door range and 60/70 mm backset options give the installer clear measurements to check at the start. It suits a full lock replacement where both the outer body and inner handle clearances are available.

Everyday access

Supported access methods: fingerprint; PIN; RFID; mechanical key; Yale Home app with kit. Choose the methods that fit the people using this doorway, then demonstrate them during installation. Digital credentials are most useful when residents understand both everyday operation and the backup procedure for their particular lock.

Key features and specifications

• Door thickness: 45–90 mm
• Backset: 60 / 70 mm
• Battery: 4 × AA alkaline
• Front dimensions: 68 × 335 × 64.5 mm

Compatibility and installation

Confirm the supplied backset, required Yale Home connectivity accessories and any optional remote control. The BioSecure model name does not by itself establish a hygiene certification or compatibility with other smart-home hubs.

For a replacement project, send photographs of both door faces, the door edge and the frame. Include the thickness, current lock model and the access methods your household wants. These details help distinguish a suitable replacement from a door that needs preparation work.

Set up for the household

Set up the owner account and any required accessories during commissioning, then test the intended local and remote functions separately. Give each regular user an appropriate credential and review access when household arrangements change.

Frequently asked questions

Will it fit my existing door?

A model name and door thickness are not enough to confirm fit. The installer also needs to check the mounting template, available clearances, strike position and the condition of the door and frame. Complete that assessment before modifying the door.

What should be confirmed before ordering?

Confirm the exact Indian-market model, finish, package contents and installation scope. Any required connectivity hardware or optional accessories should be identified in the quotation. Share your preferred access methods so the supplied configuration can be checked against them.

Availability and enquiries

Out of stock at Smartify. Enquire to register your interest or discuss an available alternative. Availability, price, regional version and warranty will be confirmed before any order; no restock date is promised.
